Parameters
Material: Nickel Plated Brass
Working temperature: -40℃~+100℃, short time can be up to +120℃.
Protection degree: IP68
O-ring: NBR
Hermetic: NBR
Claw: PA66(Nylon)
Working temperature: -40℃~+100℃, short time can be up to +120℃.
Protection degree: IP68
O-ring: NBR
Hermetic: NBR
Claw: PA66(Nylon)
|
Model
|
Specification
|
(mm)
Clamping Range |
AG (mm)
|
GL (mm)
|
H(mm)
|
Wrench Size (mm)
|
|
TOGLEX-DL-M12
|
M12x1.5
|
3~6.5
|
12
|
8
|
26
|
14
|
|
TOGLEX-DL-M16
|
M16x1.5
|
4~8
|
16
|
8
|
30
|
17/18
|
|
TOGLEX-DL-M18
|
M18x1.5
|
5~10
|
18
|
9
|
30
|
20
|
|
TOGLEX-DL-M20
|
M20x1.5
|
6~12
|
20
|
9.5
|
30.5
|
22
|
|
TOGLEX-DL-M22
|
M22x1.5
|
10~14
|
22
|
9.5
|
30.5
|
24
|
|
TOGLEX-DL-M25
|
M25x1.5
|
9~16
|
25
|
12
|
30.5
|
27
|
|
M25x1.5
|
13~18
|
25
|
12
|
34.5
|
30
|
|
|
TOGLEX-DL-M27
|
M27x1.5
|
13~18
|
27
|
12
|
34.5
|
30
|
|
TOGLEX-DL-M28
|
M28x1.5(2)
|
13~18
|
28
|
12
|
34.5
|
30
|
|
TOGLEX-DL-M32
|
M32x1.5(2)
|
15~22
|
32
|
12
|
36
|
35
|
|
TOGLEX-DL-M37
|
M37x1.5(2)
|
18~25
|
37
|
12.5
|
43
|
40
|
|
TOGLEX-DL-M40
|
M40x1.5(2)
|
18~25
|
40
|
15
|
43
|
45
|
|
M40x1.5(2)
|
22~30
|
40
|
15
|
43
|
45
|
|
|
TOGLEX-DL-M47
|
M47x1.5(2)
|
25~32
|
47
|
15
|
48
|
50
|
|
TOGLEX-DL-M50
|
M50x1.5(2)
|
32~38
|
50
|
15
|
50
|
57
|
|
TOGLEX-DL-M54
|
M54x1.5(2)
|
32~38
|
54
|
15
|
50
|
57
|
|
TOGLEX-DL-M60
|
M60x1.5(2)
|
37~44
|
60
|
15
|
50
|
64/68
|
|
TOGLEX-DL-M63
|
M63x1.5(2)
|
37~44
|
63
|
15
|
50
|
64/68
|
